Ceramic tile underlays form a flat surface for floor tiles
Cemintel Ceramic Tile Underlay
Key Features
An internal Ceramic Tile Underlay (CTU) for rooms including bathrooms, laundries and other wet areas as well as dry areas. It provides a thinner underlay substrate ideal for ceramic floor tiles. Being just 6mm thick, it minimises floor level variation with those in surrounding areas.
Use the fibre cement underlay to lay floor tiles over existing flooring like particle board flooring or plywood substrates. Cemintel Ceramic Tile Underlay is highly durable. It doesn’t swell, warp or get damaged by rot.
The Ceramic Tile Underlay has a smooth sanded finish. It’s easily installed and is an economical choice when laying ceramic tiles over timber floors.
Explore Ceramic Tile Underlay
Ceramic Tile Underlay
Ceramic Tile Underlay
Disclaimer: Product images and samples may vary from actual product regarding colour and surface finish due to the manufacturing process and raw materials used.
Technical Information
Ceramic Tile Underlay Information
Ceramic tiles are highly durable and will last for years. Even with heavy foot traffic. Ceramic tile underlays are required to ensure tiles are installed on a flat surface with good tile adhesion. This will help prevent tiles cracking and coming loose.
Ceramic Tile Underlay Installation
Lay the fibre cement underlay sheets in a staggered pattern. They should be ninety degrees to the direction of existing flooring substrate joints. Butt sheets tightly together. Then, ensure joints don’t coincide with the joints in the existing floor.
Underlay sheets should finish approximately 3mm from walls and other projections.
Ceramic Tile Underlay Product Specifications
| Product Code | Web Description | Width (mm) | Length (mm) | Thickness (mm) | Surface Texture | Finish | Groove Spacing (mm) | Effective Cover Per Unit (m2) | Effective Width (mm) | Mass (kg/m2) | Weight Per Unit | Product Warranty (Years) | BAL |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 10243 | Ceramic Tile Underlay | 900 | 1800 | 6 | Smooth | Pre-primed: polyacrylic coating | n/a | 1.62 | 900 | 9.4 | 15.23 | 25 | n/a |
| 450720 | Ceramic Tile Underlay | 1200 | 1800 | 6 | Smooth | Pre-primed: polyacrylic coating | n/a | 2.16 | 1200 | 9.4 | 20.3 | 25 | n/a |
| 450740 | Ceramic Tile Underlay | 600 | 1800 | 6 | Smooth | Pre-primed: polyacrylic coating | n/a | 1.08 | 600 | 10.6 | 10.6 | 25 | n/a |
